Fundamental Technologies

Voyager LECP Pages

February 6, 1979
Channel A

A1 One-Shot Out (J11-23)

Input Rate Output Rate
12.6 kc 12.5 kc
55.1 49.7
79 68
134 102
196 146
256 180
410 254
676 346

A2 (FF Out)

In Out
13.7 kc 6.8 kc
21.8 10.6
41.5 19.7
64.4 29.7
126 54
175 72
205 83
326 116
456 142
677 178

A0 (รท8 Output FF)

In Out
12.6 kc 1.61 kc
20.9 2.69
41.0 5.42
76.9 9.93
114 14.7
177 23.5
353 51.0
499 78.8
678 123

Figure: Feb. 6, 1979, LECP SN02, A0, A1, A2 Outputs, Random Rate Inputs

(Figure restoration in progress; please check back.)

Return to Voyager LECP Data Analysis Handbook Table of Contents.
